Manufacturer: YEALINK
Avanzada 7 code: 0010010740020
Manufacturer SKU: SIP-T29G
Unidades en la cesta: 0
Terminal IP Yealink T29G (sin fuente)
-
Enterprise HD IP Phone
SIP-T29G
SIP-T29G IP Phone is the most advanced model in the Yealink T2x IP terminal series. It has a high-resolution TFT color display,delivers a rich visual experience.
Yealink Optima HD technology enables rich, clear, life-like voice communications.Supports Gigabit Ethernet, a variety of device connections, including EHS headset and USB. With programmable keys, the IP Phone supports vast productivity enhancing features.
Features
- Yealink Optima HD voice
- Dual-port Gigabit Ethernet
- 4.3" 480 x 272-pixel color display with backlight
- Built-in a USB port, support Bluetooth headset (Through
- USB Dongle)
- Up to 16 SIP accounts
- Paper label free design
- PoE support
- Headset, EHS support
- Supports expansion modules
- Stand with 2 adjustable angles
- Wall mountable
- Simple, flexible and secure provisioning options
Specification
Audio Features
- HD voice: HD handset, HD speaker
- Codecs: G.722, G.711(A/μ), G.723, G.729AB, G.726, iLBC
- DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO
- Full-duplex hands-free speakerphone with AEC
- VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
- 16 VoIP accounts
- Call hold, mute, DND
- One-touch speed dial, hotline
- Call forward, call waiting, call transfer
- Group listening, SMS, emergency call
- Redial, call return, auto answer
- 3-way conferencing
- Direct IP call without SIP proxy
- Ring tone selection/import/delete
- Set date time manually or automatically
- Dial plan
- XML Browser
- Action URL/URI
- Integrated Screenshots
- RTCP-XR
Directory
- Loal phonebook up to 1000 entries
- Black list
- XML/LDAP remote phonebook
- Intelligent search method
- Phonebook search/import/export
- Call history: dialed/received/missed/forwarded
IP-PBX Features
- Busy Lamp Field (BLF)
- Bridged Line Apperance(BLA)
- Anonymous call, anonymous call rejection
- Hot-desking
- Message Waiting Indicator (MWI)
- Voice mail
- Call park, call pickup
- Intercom, paging
- Music on hold
- Call completion
- Call recording
Display and Indicator
- 4.3" 480 x 272-pixel color display with backlight
- 16 bit depth color
- LED for call and message waiting indication
- Dual-color (red or green) illuminated LEDs for line status information
- Wallpaper
- Intuitive user interface with icons and soft keys
- National language selection
- Caller ID with name, number and photo
Feature keys
- 10 line keys with LED
- 10 line keys can be programmed up to 27 various features (3-page view)
- 8 features keys: message, headset, conference, hold, mute, transfer, redial, hands-free speakerphone
- 4 context-sensitive “soft” keys
- 6 navigation keys
- 2 Volume control keys
- Illuminated message key
- Illuminated headset key
Interface
- Dual-port Gigabit Ethernet
- Support Bluetooth headset through USB Dongle
- 1xRJ9 (4P4C) handset port
- 1xRJ9 (4P4C) headset port
- 1XRJ12 (6P6C) EXT port:
- Supports up to 6 Expansion Modules for an attendant console application
- Power over Ethernet (IEEE 802.3af), class 3
Other Physical Features
- Stand with 2 adjustable angles
- Wall mountable
- External universal AC adapter (optional): AC 100~240V input and DC 5V/2A output
- Power consumption (PSU): 1.8-5.4W
- Power consumption (PoE): 2.1-8.0W
- Dimension(W*D*H*T):
- 244mm*213mm*185mm*54mm
- Operating humidity: 10~95%
- Operating temperature: -10~50°C
Management
- Configuration: browser/phone/auto-provision
- Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
- Auto-provision with PnP
- BroadSoft device management
- Zero-sp-touch, TR-069
- Phone lock for personal privacy protection
- Reset to factory, reboot
- Package tracing export, system log
Network and Security
- SIP v1 (RFC2543), v2 (RFC3261)
- Call server redundancy supported
- NAT transverse: STUN mode
- Proxy mode and peer-to-peer SIP link mode
- IP assignment: static/DHCP/PPPoE
- HTTP/HTTPS web server
- Time and date synchronization using SNTP
- UDP/TCP/DNS-SRV(RFC 3263)
- QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
- SRTP for voice
- Transport Layer Security (TLS)
- HTTPS certificate manager
- AES encryption for configuration file
- Digest authentication using MD5/MD5-sess
- OpenVPN, IEEE802.1X
- IPv6
Package Features
- Qty/CTN: 5 PCS
- N.W/CTN:
- G.W/CTN:
- Giftbox size: 274mm*258mm*142mm
- Carton Meas: 732mm*286mm*266mm
-
- GigabitYES
- Numero de puertos RJ452 x 10/100/1000M Ethernet Ports
- BLF10 keys
- Numero de lineas
- Conector para cascosRJ9 (EHS support)
- Numero de cuentas SIPUp to 16 SIP accounts
- PoEYes
- Fuente de alimentacionOptional
- Teclados de expansiónSupports up to 6 Expansion Modules
- Pantalla tactilNO
- Pantalla colorYES
- WifiNO
- BluetoothYES (through USB Dongle)
- Display4.3" 480 x 272-pixel color screen with backlight
- HandFreeYES
- VPNOpenVPN, IEEE802.1X
- USBYES
-
- DatasheetYealink SIP-T29G Datasheet.pdf
- Quick start guideYealink_SIP-T29G_Quick_Start_Guide_V80_20.pdf
- User manualYealink_SIP-T29G_User_Guide_V80_20.pdf
- Quick start guideT29G_Quick_Guide_V80_20_ES.pdf
